Heavy Duty Extension Sensor Cable for ABSOCODER

Extension sensor cable for heavy duty is the cable which connects an ABSOCODER sensor to converter.
Select cables from usage and environment.

Extension sensor cable

Heavy duty sensor type

Model coding

Ex. 4P-RBT-4344-□

Cable type
For 2-phase type
Code Cable type
4P-S Standard cable
4P-RBT Robotic cable
4P-URT Semi-heat-resistant robotic cable
4P-HRT Heat-resistant robotic cable
4P-RL Reel cable
For 3-phase type
(VRE-16TS100, VLS-8SM)
Code Cable type
3S-S Standard cable
3S-RBT Robotic cable
3S-URT Semi-heat-resistant robotic cable
3S-HRT Heat-resistant robotic cable
For 3-phase type
(MRE-1024S16TS100)
Code Cable type
5S-SLA Standard cable
5S-RBT Robotic cable
5S-HRT Heat-resistant robotic cable
Connector (Converter side)
Code Connector type
01 Connector for connecting to a converter
(R04-PB9M8.0A)
27 Large connector (NWPC-4012-Ad14)
43 Standard connector (NJW-2012-PM8)
51 Standard connector (NJW-2012-PM10)
90 Crimp-type terminal (R1.25-4)
91 Crimp-type terminal (R2-4)
Connector (Sensor side)
Code Connector type
26 Large connector (NWPC-4012-P14)
40 Connector for directly connecting to a sensor (NJW-2012-PF8)
44 Standard connector (NJW-2012-AdF8)
52 Standard connector (NJW-2012-AdF10)
55 Large connector (NWPC-4012-P12)
90 Crimp-type terminal (R1.25-4)
91 Crimp-type terminal (R2-4)
Cable length [Units : m]
Code Cable length
4P-S 2,3,5,8,10,15,20,25,30,35,40,45,50
4P-RBT
3S-S
3S-RBT
5S-SLA
5S-RBT
Code Cable length
4P-URT 5,10,15,20,25,30,35,40,45,50
4P-HRT
4P-RL
3S-URT
3S-HRT
5S-HRT

We will provide the cable every 10m if you would like to purchase longer than 50m.

Specification

NSD cable specifications


Item Specification
Model code 4P-S 4P-RBT 4P-RL 4P-URT 4P-HRT
Cable type Standard cable Robotic cable Reel type cable Semi-heat-resistant robotic cable Heat-resistant robotic cable
Diameter Φ8 Φ29 Φ8
Operating temperature range -5~+60℃ -30~+75℃ -5~+105℃ 0~+105℃
Characteristic Extendable for long distance Superior flexibility; ideal for moving place Heat resistance, Extensible superior flexibility that is ideal for moving part
InsulatorIrradiated cross linked foamed polyethylene ETFE plastic Ethylene propylene rubber mixture ETFE plastic
Sheath Polyvinyl chloride mixture Chloroprene mixture Heat-resistant polyvinyl chloride mixture Fluonlex
Construction 8-core, 2-pair without shield
+ 2-pair with shield
8-core,4-pair with shield 8-core, 2-pair without shield
+ 2-pair with shield
Color of sheath Gray Black
Applicable ABSOCODER VRE-P061,VRE-P074,VRE-P101
VRE-10TP068,VRE-10TP101
MRE-□SP061,MRE-□SP074,MRE-□SP101
SCHH/SCAH,CSAH,SCJJ,SCM/SCJ
IRS-51.2P,IRS-32.8P

High-resolution type sensor cable specifications


Item Specification
Model code 3S-S 3S-RBT 5S-RBT 5S-SLA 3S-URT 3S-HRT 5S-HRT
Cable type Standard cable Robotic cable Standard cable Semi-heat-resistant robotic cable Heat-resistant robotic cable
Diameter Φ8 Φ8.5 Φ20.5 Φ8 Φ9.5 Φ11.5
Operating
temperature
range
-5~+60℃ -5~+105℃ 0~+105℃
Characteristic Extendable for long distance Superior flexibility; ideal for moving place Extendable for long distance Superior flexibility; ideal for moving place Heat resistance, superior flexibility that is ideal for moving part
InsulatorIrradiated cross linked foamed polyethylene ETFE plastic Irradiated cross linked foamed polyethylene ETFE plastic
Sheath Polyvinyl chloride mixture Heat-resistant polyvinyl chloride mixture Fluonlex
Construction 7-core 1-triple with shield
+ 2-pair with shield
11-core 1-triple with shield
+ 4-pair with shield
7-core 1-triple with shield
+ 2-pair with shield
7-core 1-triple with shield
+ 2-pair with shield
11-core 1-triple with shield
+ 4-pair with shield
Color of sheath Dark brown Blue Dark brown Blue Black
Applicable
ABSOCODER
VRE-16TS100
VLS-8SM
MRE-1024S16TS100 VRE-16TS100
VLS-8SM
MRE-1024
S16TS100

Combination

Single-turn type ABSOCODER sensor VRE
Multi-turn type ABSOCODER sensor MRE
Smart Linear Position Sensing Cylinder CYLNUC
Cylinder In Rod Linear Position Sensor Inrodsensor

Ex.

Extension Sensor Cable Heavy Duty 4P-S-0144,4P-RBT-0144,4P-URT-0144,4P-S-4344,4P-RBT-4344,4P-URT-4344,4P-HRT-4344,4P-S-9044,4P-RBT-9044,4P-URT-9044,4P-HRT-9044,4P-S-0190,4P-RBT-0190,4P-URT-0190

Ex.

Extension Sensor Cable Heavy Duty 4P-S-0155,4P-RBT-0155,4P-URT-0155

Ex.

Extension Sensor Cable Heavy Duty 4P-S-9090,4P-RBT-9090,4P-URT-9090,4P-HRT-9090,4P-S-0190,4P-RBT-0190,4P-URT-0190,4P-RL-9191

Ex.

Extension Sensor Cable Heavy Duty 4P-S-9090,4P-RBT-9090,4P-URT-9090,4P-HRT-9090,4P-S-0190,4P-RBT-0190,4P-URT-0190



High-resolution Single-turn type ABSOCODER sensor VRE
High-resolution Linear type ABSOCODER sensor VLS

Ex.

Extension Sensor Cable Heavy Duty 3S-S-0144,3S-RBT-0144,3S-URT-0144,3S-S-4344,3S-RBT-4344,3S-URT-4344,3S-HRT-5152,3S-S-9044,3S-RBT-9044,3S-URT-9044,3S-HRT-9052,3S-S-0190,3S-RBT-0190,3S-URT-0190

Ex.

Extension Sensor Cable Heavy Duty 3S-S-9090,3S-RBT-9090,3S-URT-9090,3S-S-0190,3S-RBT-0190,3S-URT-0190



High-resolution Multi-turn type ABSOCODER sensor MRE

Extension Sensor Cable Heavy Duty 5S-RBT-4355,5S-RBT-4344,5S-SLA-5756



Dimensions

Extension Sensor Cable
4P-S-0144 / 4P-RBT-0144 / 4P-URT-0144

Extension Sensor Cable 4P-S-0144/4P-RBT-0144/4P-URT-0144



Extension Sensor Cable
4P-S-4344 / 4P-RBT-4344 / 4P-URT-4344 / 4P-HRT-4344

Extension Sensor Cable 4P-S-4344/4P-RBT-4344/4P-URT-4344/4P-HRT-4344



Extension Sensor Cable
4P-RL-9191

Extension Sensor Cable 4P-RL-9191



Extension Sensor Cable
4P-S-0155 / 4P-RBT-0155 / 4P-URT-0155

Extension Sensor Cable 4P-S-0155/4P-RBT-0155/4P-URT-0155



Extension Sensor Cable
4P-S-0190 / 4P-RBT-0190 / 4P-URT-0190

Extension Sensor Cable 4P-S-0190/4P-RBT-0190/4P-URT-0190



Extension Sensor Cable
5S-RBT-4355

Extension Sensor Cable 5S-RBT-4355



Extension Sensor Cable
4P-S-9044 / 4P-RBT-9044 / 4P-URT-9044 / 4P-HRT-9044

Extension Sensor Cable 4P-S-9044/4P-RBT-9044/4P-URT-9044/4P-HRT-9044



Extension Sensor Cable
4P-S-9090 / 4P-RBT-9090 / 4P-URT-9090 / 4P-HRT-9090

Extension Sensor Cable 4P-S-9090/4P-RBT-9090/4P-URT-9090/4P-HRT-9090



Restrictions when extending the cable length with mixing following cables; standard, JKPEV-S, robotic, semi-heat-resistant robotic, and heat-resistant robotic

When extending the cable connecting the converter to the sensor, a standard cable (S) or JKPEV-S cable is used at the fixed area, and a robotic cable (RBT), semi-heat-resistant robotic cable(URT), or heat-resistant robotic cable (HRT) is used at the movable area.

In cases such as this, where both cable types are used in the extension, the maximum cable length is shorter than when using a standard cable only.
Therefore, be sure that the length is within the prescribed range.

If the prescribed length is exceeded, abnormal operation may occur. The required robotic cable length should be determined first, then calculate the maximum standard cable extension length using the method shown here.

(1) Refer to the information about your converter or controller to find specifications for the longest allowable extended sensor cable length for each cable type (the allowable length varies depending on the converter and sensor combination).

 a. Maximum standard cable extension length:L1 (m)
 b. Maximum robotic cable extension length:L2 (m)

(2) The robotic cable length (Lr) should be determined with reference to the drawing, and by measuring, etc.
Be sure that the "b (L2)" length given above is not exceeded.

(3) The maximum standard cable extension length (Ls) can be calculated using the formula shown below.



Calculation formula

Ls(m): Standard or JKPEV-S cable

Lr(m): Robotic, semi-heat-resistant robotic, or heat-resistant robotic cable

Cable length calculation formula

Cable configuration

Cable configuration
